Description EIT’s MicroCure® measurement system is comprised of two separate stand-alone items; the data collection radiometer which is placed in the ultraviolet (UV) environment to be measured, and a DataReader which reads and displays the measurement results from the radiometer. The UV integrating radiometer is a microprocessor-based, electro-optical instrument that measures and accumulates the total UV energy that is applied to the measurement surface of the instrument. The MicroCure® radiometer measures the total amount of UV energy that would be impinged on a work piece passing through the curing system and the peak UV irradiance. The radiometer combines very small physical size and adaptability to address a variety of demanding physical and thermal measurement environments. Features Small Size: 1.3” x 0.95” x 0.25” Lightweight: 0.33 ounces Measures total energy density in Joules/cm² Measures peak power density in Watts/cm² Battery powered High sample rate: 2000 Samples per second Automatic operation High temperature resistance Applications UV systems requiring small size and automatic operation Small container curing (bottles, cans, etc.) Three-dimensional objects Web printing Very small conveyorized and batch applications (semiconductor printing, small part bonders, etc.) Statistical Process Control measurements MicroCure Technical Specifications
