Bespoke MaxxECU Harness wiring loom for a 4-Cylinder Engine – Fly By Wire

Description A completely bespoke harness for your 4-Cylinder engine We build a harness for your MaxxECU (Purchased from us) to your specifications for your engine. How does this work? We build a loom based on the details you send us. In some cases, you may be replacing an older out of date ECU & loom, in this case, you could send us the old loom. We can then use this as a pattern to copy the lengths of wiring and connector styles. If you don’t have an old loom, you can do one of two things; You can draw out your loom. Measure carefully each length and make a drawing of the loom you are after. If you know the types of connectors you have, then brilliant, If not, some photographs of the connectors. All this can be E-Mailed over, until we’ve got a design we are happy with. Or, you can make a mock up loom of what you want out of string, or cable. I show you a small example of this in one of my Youtube videos: From around 10 minutes in: Jaguar XKR Youtube link for wiring Once we have our design sorted, and we are both happy we can then build up your harness. The base harness is built using the automotive grade PVC thinwall cable supplied with your MaxxECU loom kit. If you have not purchased this from us this is available at extra cost, or you are going for one of the higher options that does not use the supplied loom kit, then this is supplied by us at our cost. Basic Loom Specifications Your loom will be braided with Vidaflex® Monofil PE, this offers very good mechanical strength and also provide excellent resistance to salt water, oil, fuels and solvents. It is self-extinguishing and operates at temperatures within the range of – 70°C to 150°C. The junctions are adhesive heat shrunk and all applicable connectors are booted. We provide a single bulkhead grommet (51mm hole required) obviously pre-fitted to each loom. The grommet can taper either way to customers request. Near the ECU we utilise the GT150 12-Way connector, using the standard pinout supplied with MaxxECU. This allows for a very easy connection to the vehicle. It will also connect straight into the MaxxECU Fuse box, to ensure a quick and trouble free installtion. No solder used anywhere, all junctions and connectors are professionally crimped, using professional high end crimp tools. Included connections allowable in the basic package are: 1 x Lambda 4 x Injectors Cam Sensor Crank Sensor Throttle Body Connector Throttle Pedal Connector Air Temp Coolant Temp Ignition Coils x 4 3 x Aux (Temp, boost etc) Extra connectors can be added at a further cost. Please discuss with us first. We can quote you. This is the Fly-By-Wire Version, for the Cable Throttle version -> Click Here! Spec44 Upgrade: The above package can be upgraded to the Spec44 / DR25 spec. This is a good motorsport grade package. The entire loom is concentrically twisted using Spec44 cable. It is covered in DR25 heat shrink. The transitions, and backshells (if required) are shrunk with ATUM. A great value motorsport level system that has proven very popular. Our looms are built to high quality, we have invested in all the relevant genuine tooling to ensure absolute reliability long term. We have total confidence in each loom we build. Each loom is load tested as required. You can expect delivery of your loom no longer than 6-Weeks from payment.
